Crystallite electric film Mica heating board(convection)

Crystallite electric film Mica heating board(convection) Crystallite electric film Mica heating board(convection)
Product name:Crystallite electric film Mica heating board(convection)
Item:
Details:

ITEM:MH-D
We can provide variety of mica heating board according to your unique designs.



Features:
1、Cost effective,more efficient
Convert more than 96% electrical energy into heat.
2、No adhesive and no fume,more environment-friendly
Mica heating board is made of natural material,no adhesive connection and no fume.
3、Parallel circuit design,more durable
Compared with traditional series circuit design,the life time of heating elements could be5-10 times longer.
4、Fast temperature increase
Switch on and warm almost instantly.
5、Overheat protection,much safer
As a application of aerospace self-protective design,it will cut off the circuit to ensure security use when over heating or over current occupied caused by thunder strike or other causes.
6、Far infrared physical therapy,much greener
It is proved that more than 78% electric energy could be converted into far infrared radiation.When applied in medical and health care,far infrared radiation can activate blood circulation,relieve joint pain,dissipate blood stasis,relax nervous tension,decrease body fat,intensify liver function,strengthen immune system. It is a far infrared therapist more than just a heater.



Application: applied in convection room heater with close touch with metal plate. Feature:1mm thickness,flat surface,planar heat source,80~100 degrees centigrade working temperature,even heat coverage

Specifications:
Working temperature:≤330℃
Rated voltage:AC/DC 3~380V
Withstand voltage:2000V,1min
Creepage current:≤0.75mA
Life time:≥3000 hours

Power variation curve
